Click here to see similar items on eBay, and to buy.
Pristine 24-bit/192kHz A/D and D/A converters (A/D and D/A: 112dB measured SNR performance) deliver unmatched USB audio fidelity for pristine audio quality
Preamplified analog signals are available before the A/D converters, allowing the Tracker Pre to be used as a standalone high-quality stereo microphone preamp (using optional power supply)
Hardware zero-latency direct monitoring (mono or stereo) with continuously variable level control
Plug-and-play operation with hands-on control of all major functions like direct monitoring level, headphone level, preamplifier gain and more
Independent ground lift switches for optimal audio fidelity/flexibility
USB bus powered (can also be powered using optional 5V power supply)
Cross-platform support (Mac OS X and Windows XP32/XP64/Vista32/Vista64) and compatibility with most popular audio/sequencer applications (ASIO2, WDM, MME, Apple Core Audio and Core MIDI supported)
General
Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz from internal crystal (no sample rate conversion)*
Bit Depth: 24-bit I/O, 32-bit processing
USB 2.0 Hi-Speed
– Full 24-bit resolution at all sample rates
– Stereo in, stereo out at all sample rates
Zero-latency direct hardware monitoring (disabled at 176.4-192kHz)
Windows drivers: ASIO2 and WDM
Macintosh driver: Apple CoreAudio
Anti-Pop speaker protection minimizes noise during power on/off
Ultra-low jitter clock subsystem: < 100ps RMS
USB Bus or AC powered via optional Universal Power Supply
Combo Preamplifiers (2)
Type: E-MU Current Morph combo mic preamp and Hi-Z/line input
A/D converter: AK5385
Max Level: +6.4dBV bal/unbal (+6.9 dBu)
– Hi-Z/line balanced input: +6.9dBV bal/unbal (+9.1dBu)
– Microphone Preamplifier: +6.4dBV bal/unbal (+8.6dBu)
Frequency Response (min gain, 20Hz-20kHz): +0.0/-0.03dB
Dynamic Range (A-weighted, 1kHz, min gain): 112dB
Signal-to-Noise Ratio (A-weighted, min gain): 112dB
THD+N (1kHz at – 1dBFS, min gain): -102dB (.0007%)
EIN (20Hz-20kHz, 150ohm, unweighted): -127dBu
Input Impedance
– Hi-Z/line balanced input: 1Mohm
– Microphone Preamplifier: 1.5Kohms
Analog Line Outputs (2)
Type: balanced, AC-coupled, 2-pole low-pass differential filter
D/A converter: CS4392
Max Level: 6.6 dBV (unbalanced)
Frequency Response (20Hz – 20kHz): 0.00/-0.08dB
Dynamic Range (1kHz, A-weighted): 112dB
Signal-to-Noise Ratio (A-weighted): 112dB
THD+N (1kHz at -1dBFS): -99dB (.0011%)
Stereo Crosstalk (1kHz at -1dBFS): <-111dB
Headphone Amplifier
Type: Class-A power amplifier
D/A converter: CS4392 (shared with Line Out)
Gain Range: 60dB
Maximum Output Power: 22mW
Output Impedance: 22ohms
Frequency Response (20Hz-20kHz): +0.02/-0.07dB
Dynamic Range (A-weighted): 112dB
Signal-to-Noise Ratio (A-weighted): 112dB
THD+N (1kHz, max gain): 300ohm load: -99dB (.0011%)
Adapter not included*
